主要功能介绍：
spectrogon,中性密度红外滤光片
021-50710257
13331917708(微信同号)
standard neutral density filters in stock, subject to prior sales
general specifications:
diameter: 25.4 mm 0/-0.2 mm. custom sizing
thickness: specified in the filter list below (mm), tol ±0.1 mm
ir nd filters are designed for 2000-16000 nm
nd uv-vis filters are designed for 190-1100 nm
vis nd filters are designed for 400-800 nm
spectral measurements:
spectral curve at room temperature and normal incidence angle is supplied with each filter type.
click on the description, to see spectral characteristics for the filters in stock.
description | substrate | thk | t-low | t-high | t % | t tol |
nd-ir-od-0.3-ø25.4x1.0 mm | ge | 1.00 | 2000,00 | 15000,00 | 50,00 | 5,00 |
nd-ir-od-0.3-ø50.8x1.0 mm | ge | 1.00 | 2000,00 | 15000,00 | 50,00 | 5,00 |
nd-ir-od-0.6-ø25.4x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 25,00 | 3,00 |
nd-ir-od-0.8-ø25.4x0.5 mm | ge | .50 | 2000,00 | 16000,00 | 15,80 | 2,00 |
nd-ir-od-1.0-ø25.4x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 10,00 | 2,00 |
nd-ir-od-1.0-ø50.8x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 10,00 | 2,00 |
nd-ir-od-1.45-ø25.4x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 3,50 | 0,80 |
nd-ir-od-1.45-ø50.8x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 3,50 | 0,80 |
nd-ir-od-2.0-ø25.4x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 1,00 | 0,25 |
nd-ir-od-2.0-ø50.8x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 1,00 | 0,25 |
nd-ir-od-3.0-ø25.4x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 0,10 | 0,05 |
nd-ir-od-3.0-ø50.8x1.0 mm | ge | 1.00 | 2000,00 | 16000,00 | 0,10 | 0,05 |
nd-uv-vis-od-0.3-ø25.4x0.5 mm | quartz | .50 | 190,00 | 2500,00 | 50,00 | 10,00 |
nd-uv-vis-od-0.6-ø25.4x0.5 mm | quartz | .50 | 190,00 | 2500,00 | 25,00 | 5,00 |
nd-uv-vis-od-1.0-ø25.4x0.5 mm | quartz | .50 | 190,00 | 2500,00 | 10,00 | 2,00 |
nd-uv-vis-od-1.45-ø25.4x0.5 mm | quartz | .50 | 190,00 | 2500,00 | 3,50 | 2,50 |
nd-uv-vis-od-2.0-ø25.4x0.5 mm | quartz | .50 | 190,00 | 2500,00 | 1,00 | 0,50 |
nd-ir filter set, consisting of 6 types ø25.4x1.0 mm filters with od: 0.3, 0.6, 1.0, 1.45, 2.0 and 3.0
nd-ir filter set, consisting of 6 types ø50.8x1.0 mm filters with od: 0.3, 0.6, 1.0, 1.45, 2.0 and 3.0
nd-uv-vis filter set, consisting of 6 types ø25.4x1.0 mm filters with od: 0.3, 0.6, 1.0, 1.45, 2.0 and 3.0
